Security Advisory Description

BIG-IP APM AD (Active Directory) authentication can be bypassed using a spoofed AS-REP (Kerberos Authentication Service Response) response sent over a hijacked KDC (Kerberos Key Distribution Center) connection, or from an AD server compromised by an attacker.

Impact — CVE-2021-23008

However, A remote attacker can hijack a KDC connection using a spoofed AS-REP response.

In addition, For an APM access policy configured with AD authentication and SSO (single sign-on) agent, if a spoofed credential related to this vulnerability is used, depending how the back-end system validates the authentication token it receives, access will most likely fail.

An APM access policy can also be configured for BIG-IP system authentication.

Also, A spoofed credential related to this vulnerability for an administrative user through the APM access policy results in local administrative access.

Vulnerable Platforms

To determine if your release is known to be vulnerable, the components or features that are affected by the vulnerability, and for information about releases, point releases, or hotfixes that address the vulnerability, refer to the following table

Product	Branch	Versions known to be vulnerable	Fixes introduced in	Severity	CVSSv3 score1	Vulnerable component or feature
BIG-IP APM	16.x	16.0.0 – 16.0.1	None	High	8.1	APM AD auth
	15.x	15.0.0 – 15.1.2	15.1.3
	14.x	14.1.0 – 14.1.3	14.1.4
	13.x	13.1.0 – 13.1.3	13.1.4
	12.x	12.1.0 – 12.1.5	12.1.6
	11.x	11.5.2 – 11.6.5	None
BIG-IP (LTM, AAM, AFM, Analytics, ASM, DNS, FPS, GTM, Link Controller, PEM)	16.x	None	Not applicable	Not vulnerable	None	None
	15.x	None	Not applicable
	14.x	None	Not applicable
	13.x	None	Not applicable
	12.x	None	Not applicable
	11.x	None	Not applicable
BIG-IQ Centralized Management	7.x	None	Not applicable	Not vulnerable	None	None
	6.x	None	Not applicable
	5.x	None	Not applicable
Traffix SDC	5.x	None	Not applicable	Not vulnerable	None	None

Security Recommendations:

Furthermore. If you are running a version listed in the Versions known to be vulnerable column, you can eliminate this vulnerability by upgrading to a version listed in the Fixes introduced in column.

Also, If the table lists only an older version than what you are currently running, or does not list a non-vulnerable version, then no upgrade candidate currently exists.

Mitigation

APM access policy

However, To mitigate this vulnerability, you can configure multi-factor authentication (MFA), or host-level authentication, such as deploying an IPSec tunnel between the affected BIG-IP APM system and the AD servers.

BIG-IP System authentication

However, If BIG-IP system authentication uses AD authentication from an APM access policy, you can use an alternative remote authentication option from the User Directory options that have the SSL-based authentication feature.

In addition, The key configuration enables the ‘SSL’ option and configures it as needed for the listed remote authentication alternative configurations:
